Microblade Damper

Opposed Blade Aluminum Micro Damper

Our Microblade Opposed Blade Dampers feature a 50mm / nominal 2” blade, all aluminum construction, and a fiberglass reinforced nylon gearing system that is housed internally. No failure due to rust, corrosion, or debris accumulation. All of our dampers are made to order with short lead times.

Product Construction Details:

Blade

Material: Aluminum 6063
Dimension: 2 in / 50 mm
Treatment: T5
Finish: Mill
Gasket: Thermoplastic Rubber

Frame
Nominal 2 in wide, U-shape

Blade Blocks
Material: Polyammide and fiberglass PA6 + GF 20%
Color: Black

Gears
Material: Copolymer polypropylene and fiberglass
*Optional flame retardant V-5

Control
5/16 in / 8 mm Square Control Shaft

Working Temperature
Minimum: -15 °C
Maximum: 80 °C

Download Spec Sheet

MFS 2019 Micro Damper Product Flyer



Micro Damper Quote Request

  • Please provide dimensions in inches, quantities, and any specific information required for your dampers. Example 1: Qty of 3 Dampers 24"w x 12"h / Example 2: Qty of 1 Damper 30"w x 10"h with 2 equal size sections / Example 3: Qty of 1 Face & Bypass Damper with a 24" face, 12" bypass, and internal height of 16"
