Flexible Connection

Flexible Duct Connection

The APS Arosio flexible duct connector is a system designed to be attached between the fan/blower and the discharge flange in an AHU to isolate vibration and reduce noise from within the system. The air tight flexible PVC fabric is secured to the frame using the Arosio stopper system clip extrusion. The fabric is joined together at the seam using a thermal welder.

Product Construction Details:

Frame

Material: Aluminum 6063 and 6060
Dimension: 30mm and 45mm options with stock lengths of 236 in / 6 m
Treatment: T5 and T6
Finish: Mill

Die-Cast Corners
Material: ZAMA
Finish: Natural

Fabric
Material: PVC
Color: Grey

Working Temperature
Working condition range of -25°C to 70°C

Download Spec Sheet

MFS 2019 Flex Connection Spec Sheet

Flexible Connection Quote Request

Company Name
Name*
First Last
Phone
Email*
Frame Size*
- 30mm Frame
- 45mm Frame
- 45mm Frame with Flange
Fabric Width*
- 2" Wide Fabric
- 4" Wide Fabric
- 6" Wide Fabric
Damper Information*
Please provide dimensions in inches, quantities, and any specific information required for your Flexible Connection. Example 1: Qty of 3 Flexible Connections with 45mm Frame, 4" fabric, 24"w x 48"h overall outside dimension / Example 2: Qty of 1 Flexible Connection with 30mm Frame, 6" fabric, with air opening size of 15"w x 15"h
