150-25 System

Part# AC530-25 Branches 3
Nominal Dimension 1.97 in / 50 mm
Panel Thickness 0.984 in / 25 mm
Weight 1.102 Lbs / 500 g
Material EN AB 46100
Modulus of Elasticity N/A
Finish Natural
Available in Nylon Reinforced Fiberglass AFG530-25



Part# P150-25 Corner Profile / Perimeter 1.97 in / 50 mm
Panel Thickness 0.98 in / 25 mm
Max Profile Length 240 in / 20 ft
Weight 0.734 Lbs/ft  /  1.092 Kg/m
Material Aluminum 6063
Finish Natural
Treatment T5
Available in Fiberglass PFG150-25



Part# GOP250-25 Omega Joint
Nominal Dimension 1.97 in / 50 mm
Panel Thickness 0.984 in / 25 mm
Weight 0.139 Lbs / 63 g
Material EN AB 46100
Modulus of Elasticity N/A
Finish Natural
Available in Nylon Reinforced Fiberglass GFG250-25



Part# P250-25 Omega Profile / Intermediate 1.97 in / 50 mm
Panel Thickness 0.98 in / 25 mm
Max Profile Length 240 in / 20 ft
Weight 0.665 Lbs/ft / 0.990 Kg/m
Material Aluminum 6063
Finish Natural
Treatment T5
Available in Fiberglass—PFG250-25



Part# P251-25 Omega Profile / Intermediate 1.97 in / 50 mm
Panel Thickness 0.98 in / 25 mm
Max Profile Length 240 in / 20 ft
Weight 0.640 Lbs/ft / 0.950 Kg/m
Material Aluminum 6063
Finish Natural
Treatment T5
