Standard 120-18 System


The Standard 120-18 System is designed to assemble units requiring a nominal 3/4 inch wall thickness. Components to this system include the A230-18 Corner Joint, P120-18 Perimeter Profile, and P220-18 Omega Profile.


A230-18 – Corner Joint for P120-18 Perimeter Profile

Weight: 0.168 Lbs / 76 g

Material: EN AB 46100

Finish: Natural


P120-18 – Perimeter Profile

Material: 6063 Aluminum Extrusion

Dimensions: 0.79″W x 0.79″H with 0.59″ Flange – Stock Length 20ft

Weight: 0.289 Lbs/ft

Finish: Mill

Treatment: T5


P220-18 – Omega Intermediate Support Profile

Material: 6063 Aluminum Extrusion

Dimensions: 0.79″W x 0.79″H with 0.59″ Flange – Stock Length 20ft

Weight: 0.336 Lbs/ft

Finish: Mill

Treatment: T5
